Engineers and technicians needing higher performance test solutions for more advanced debug tasks will appreciate the unique price/performance attributes of the DS2102E. Based on our UltraVision technology the DS2102E delivers advanced performance and analysis capabilities, a large intensity graded display, and a proven and reliable hardware platform at an unprecedented price point.

Features

• 100 MHz bandwidth model
• 2 analog channels, 50 Ω input impedance (standard)
• Vertical range: 500 μV/div ~ 10 V/div
• Real-time sample rate: up to 1 GSa/s on both channels
• Memory depth: up to 28 Mpts on both channels
• Waveform capture rate: up to 50,000 wfms/s
• Real-time hardware waveform recording, playback, and analysis of up to 65,000
• captured frames
• Various serial trigger and decode (RS232/UART, I2C, SPI, CAN and LIN)
• Complete connectivity: USB DEVICE, USB Host, LAN, and optional GPIB
• 8-inch WVGA (800×480), 256-level intensity grading display
